SS316 Stainless Steel DC Motor Fastlane Turnstile

Basic Information
Place of Origin: Shenzhen,China
Brand Name: KOMAI
Certification: CE/RHOS/FCC/ISO
Model Number: KM-SP01+
Minimum Order Quantity: 1 lane
Price: Negotiable
Packaging Details: Wooden Box
Delivery Time: 7-15 days
Payment Terms: T/T, Western Union
Supply Ability: 5000 pcs/month
Material: 316 Stainless Steel Product Name: High Speed Turnstile Gate
Type: Fully Automatic Speed Lane Turnstile Gate Dimension: 1600*140*1000 (mm)
Power Supply: AC220V/110V,50/60Hz Communication: RS 232 And 485
Highlight:

DC Motor Fastlane Turnstile

,

SS316 Fastlane Turnstile

,

DC Motor 316 Stainless Steel Turnstile

316 Stainless Steel Temperated Glass DC Motor Fastlane Turnstile

Introduction:
Swing Turnstiles offer a reliable and efficient method to ensure only authorized users are allowed access to each area of a building. It is an attractive swing turnstile that is easily capable of handling high volume and abusive conditions. The compact unit makes it simple to construct a multiple lane set-up while the variety in colors allows you to match this turnstile perfectly to your lobby or branding.



Features:

High Speed Stainless Steel Fingerprints Swing Gating Turnstiles For Hygiene Station
1. A high-brightness directional light under which passage or no passage can be indicated
2. It can swipe your card to get in and out,The card can also be swiped while the other buttons are on.
3. Acrylic material, strong and durable, with mechanical and infrared induction double anti - clip function, to prevent injury
4. High quality 316 stainless steel material.
The whole product adopts high standard 316 stainless steel and adopts modern technology. Durable and resistant to friction



Advanced Features:

1). Running stably without noise and mechanical impact

2). The number of the passing persons can be counted via the built-in people counter

3). Several ways of working modes for option

4). Bi-direction or one direction permitted. One forbidden. Or one direction charged.

One for free . And all the working modes set by the buttons in the main control board

5). Beam falling and lifting can be controlled in far distance so to satisfy the special require ment of the users and the request of fire protection

6). LED Direction-guide lights in the turnstile to tell you whether the direction to go or not

7).The standard electrical interface connected with various kinds of reader and writer equipments

8). All the functions realized in one integration machine and controlled and managed by the computer in the far distance

9). The number of the persons passed can be counted automatically which can also be display in LED

10). The function with or without card-reading memory can be set according to your demand

11). Self-check and alarm for convenient to operate



Model
KM-SP01
Size
1600x140x980mm
Material
2.0mm imported SUS Polish 400# Snow line+Top Cover:12 man made marble+Filling Panel:10mm Acrylic with Led light bar
Arm material
Temperated Glass
Pass Width
650mm
Passage direction
Single directional/Bi-directional
Pass rate
35-40 persons/minute
Operating time
0.2 seconds
Power input
AC100-240V,50/60HZ
Working voltage
24V
Working humidity
30%~95%
Working temperature
-40℃~+70℃
Working environment
Indoor
Communication interface
RS485, TCP/IP,Dry contact
Mechanism
Brushless or Servo motor
Infrared sensor
6 pairs
MCBF
5,000,000 Cycles
Application
Airports, Hotels, Governemnt Halls, etc



FAQ:

1) What is Speed Gate Turnstile?
Speed Gate Turnstiles are a form of gate which allows only one person to pass at a time. This enables security to efficiently prevent potential trouble or to restrict any prohibited materials to enter into any secured premises. It can restrict passage only to people who insert /scan a ticket, an ID cards, access card , thus a turnstile can be used in the case of paid access for example public transport, or to restrict access to authorized people in corporate houses or entrances of any building.



2)Why choose KOMAI as your supplier?

We are a leading manufacturer of turnstile and speed gate in China.
We focus on pedestrian turnstile gates.
We keep stock for regular products and we can support small orders. Usually, our lead time is just 3 days.
Design products according to customers’ requirements.
Credibility: We are SGS certificated Supplier. Our customers are located over 50 countries
Gratitude: We cherish the business chance you give us and return you with quality products and good service.
Professional: We have been in this business for more than 8 years. We have a strong professional team with various experiences.
We keep doing new product development. Our goal is to enhance our competitive capacity constantly.
Price:Competitive price and good quality products
Quality: we do 100% inspection before the shipment.
Promise: we are always ready to take the responsibility if any loss caused to our customer due to our mistakes.


3)What is the Lead time?
1-3days for sample in stock;7-15days for special sample order. 7-30days for bulk order.

4)What is the Payment term?
30% deposit and the outstanding payment should be cleared before shipment.(Notify us if you have special requirements)

5) How is your Packaging?
International standard seaworthy plywood case

6)Do you provide OEM service?
Yes.we accept both OEM and ODM.
