Product Details:

Speed gate is subordinate to the access control system and is one of the important components of modern entrance and exit control. The door wing is driven by the control system to automatically open and close, and the operating mode can be selected through programming settings: As long as the entry has been verified, the door wing opens automatically. It is closed after delay, and the delay time is adjustable.

Specification:

Functions:

Automatic return function: in the normally open or normally closed mode, the gate swing will automatically return to the blocking zero position after the passing process.

Automatic reset function: (remote manual reset mode is optional)

(1) after legal traffic signal is given, no one passes within the specified passing time (adjustable), the system will automatically restore the gate swing to block zero position, cancel the passage, and do not count.

(2) Due to the abnormal or illegal passage of the system, the brake pendulum does not return to the blocking zero position. After the specified time (adjustable), the system will automatically restore the brake pendulum to the blocking zero position.

Power off and switch on function: it adopts the original leading mechanical structure in the industry, without UPS power supply. When the power is off, the system will automatically unlock the gate swing, which can be manually pushed to open state, which is convenient for evacuating people and meeting the requirements of fire protection.

Anti illegal entry function: when there is no legal traffic signal or no passing is allowed when the controlled passage, the forced swing will be regarded as illegal intrusion, and the system will automatically alarm and ensure that the lock of the gate swing.

Anti reverse intrusion function: before the end of the passage process in a certain direction, the pedestrian entering the passage from the opposite direction will be regarded as a reverse intrusion, and the system will automatically alarm and ensure that the brake swing locks and stops.

Anti reverse traffic function: in the process of passing, when the brake pendulum has swung at a certain angle, pulling the swing swing reversely will be regarded as reverse passing, and the system will automatically alarm and ensure that the brake swing locks and stops.

Anti tailing function: the infrared detector detects the pedestrian traffic condition, and the system will automatically alarm and ensure that the brake swing locks to stop action after detecting the phenomenon of tailing; the minimum recognition distance of tailing is less than 20 mm, ranking the world's leading level.

Power on self check function: when the equipment is powered on or restarted, it will automatically detect whether the function is normal or not, and it will give an alarm if it is abnormal.

Intelligent linkage alarm: including illegal intrusion, reverse intrusion, reverse traffic, tailgating, power on self-test, etc., which can be linked with other alarm monitoring equipment, and set alarm mode and parameters through software.

Anti pinch and anti collision function:

(1) infrared anti pinch: multiple pairs of infrared detectors are installed in the area close to the brake swing activity (anti pinch area). Once people or objects are detected in the anti pinch area, the brake pendulum will stop automatically; until the person or object leaves the anti pinch area, the brake pendulum will continue to act.

(2) Mechanical anti pinch: when the brake pendulum encounters obstacles in the swing process, it will bounce back instantaneously; the impact force in the swing process of the brake pendulum is within the safe range.

Anti collision function: when the brake pendulum is locked, it can withstand the impact force within the safe range. When beyond the safety range, the brake pendulum can be pushed slowly to protect the movement and pedestrians, and then it will reset automatically.

Emergency escape function: equipped with emergency escape control device, the system can automatically open the brake swing, convenient for evacuation of people (remote control).

Pass indication function: LED is installed on the top of the box to indicate the traffic status and direction (default) / other positions are installed with LED indication (optional).

Access request memory function: when more than two legal traffic signals are given at the same time (including the same direction and reverse direction), the system will memorize all traffic requests and complete each traffic action in turn (the number of memory and whether to select the memory function can be customized according to customer requirements).

Traffic restriction function: the number of people passing through can be limited by software to meet the personnel management under special circumstances. Batch setting function: multiple gates can be set and debugged in batch through software to improve efficiency and reduce maintenance cost.

Access mode: the access directions can be set independently as [controlled passage] / [free passage] / [no passage].

Working mode: normally open (default) / normally closed / open, freely switchable.

Compatibility: equipped with dry contact signal output interface and wide threshold level signal input interface, compatible with all kinds of access control controllers.

Main Function

1.Optional card reader:Rfid card ,fingerprint scanner ,face machine ,Bar code, QR code ,card collection ,intercom system ,remote control and so on

2. Access control system ,Ticketing system ,consumption system

3. Standard/customize housing design (ODM/OEM)

5. Optional entrance width(500-950mm) ,glass door size, operation speed

Applications:
Banks and insurance companies ,airports
Government buildings and instituations
Office buildings,head offices,administrative sites
Schools ,universities and colleges

FAQ:

1,Are you manufacturer or Trade Company?

We are the manufacturer,and we provide the OEM service.

2,What is your MOQ?

Any quantity is acceptable for your order. And the price is negotiable for big quantity.

3,How to ship?

By air or by sea, quantity over 10 sets better to choose by sea to reduce cost.

4,What is your delivery time?

The time of delivery is within 30 days after receipt of deposit.

5,What is the shipping port?

We ship the goods via Shenzhen Port.

6,How about the payment method?

Standard products: 30% deposit, 70% balance payment before shipment.

Customized products: 50% deposit, 50% balance payment before shipment.

Contract amount more than USD15000: 50% deposit, 50% balance payment before shipment.

T/T, Alibaba Trade Assurance.

7,How about your package?

Exported product: Wooden case package of Export exempted from inspection plus pearl wool and plastic wrap.

Domestic: Bubble wrap plus carton or pearl wool plus wooden packaging.

8,What's you warranty?

1 year time warranty.
